Description

FEATURES
Intel Core i7-14650HX Processor (30MB Smart Cache)
Up to 5.2GHz Boost Clock
Up to 798 AI TOPs Performance (GPU)
8 Performance Cores, 8 Efficient Cores
16 Cores, 24 Threads
Intel UHD Graphics with NVIDIA Advanced Optimus
16″ WUXGA (1920×1200) 165Hz IPS Anti-Glare Display
Internal Display Supports NVIDIA G-Sync
16GB (2x8GB SO-DIMM) DDR5-5600 Memory
NVIDIA GeForce RTX 5060 8GB GDDR7 Graphics
NVIDIA GeForce Game Ready & Studio Drivers
NVIDIA DLSS 4.0 Technology
NVIDIA RTX Real-Time Ray Tracing Technology
1TB M.2 2280 PCIe 4.0 x4 NVMe SSD
1x Thunderbolt 4 USB Type-C Port with DisplayPort
1x USB 10Gbps Type-C Port with DisplayPort & Power Delivery
3x USB 5Gbps Type-A Ports
1x HDMI 2.1 (FRL) Port
1x 3.5mm Combination Audio Jack
Gigabit Ethernet RJ-45 LAN Port
WiFi 6E 2×2 MIMO Dual-Band Adapter, Bluetooth 5.4
1080P Full HD Webcam with Windows Hello
TUF Gaming RGB LED Backlit Chiclet Keyboard
90Whr 4-Cell Li-Ion Battery, Fast Charging
280W AC Adapter
Colour: Jaegar Grey
Windows 11 Home 64-bit
MUX Switch for Faster Graphics Performance
ASUS Aura RGB Sync
ASUS Armoury Crate

TECHNICAL SPECIFICATIONS

Brand: ASUS
Series: TUF Gaming Series
Model: TUF Gaming F16 (FX608JMR-I71610G0W / 90NR0NB1-M003V0)

Processor
Model: Core i7-14650HX
Chipset Manufacturer: Intel
Boost Clock: 5.2GHz
Core Arrangement: 8 Performance Cores, 8 Efficient Cores
Core Count: 16 cores
Thread Count: 24 threads
Cache: 30MB Smart Cache
Lithography: Intel 7 Process

Memory
Total Installed: 16GB (2x8GB SO-DIMM)
Type: DDR5
Memory Speed: 5600 MT/s
Maximum Capacity: 64GB (2x32GB SO-DIMM) DDR5-5600
2x SO-DIMM Slot On-Board, Both Occupied

AI Acceleration
Model: NVIDIA GeForce RTX 5060
Performance: Up to 798 AI TOPs
Frameworks Supported: WindowsML, DirectML, ONNX with CUDA, Sparsity, WebGPU, CUDA, RTX AI Toolkit, TensorRT

Graphics
Integrated: Intel Graphics
Discrete: NVIDIA GeForce RTX 5060 Graphics
GPU Architecture: NVIDIA Blackwell
Execution Units: 3328 CUDA Cores
Boost Clock: 2497MHz at 115W Dynamic Boost
Memory: 8GB GDDR7
Features: NVIDIA GeForce Experience
NVIDIA ShadowPlay
NVIDIA Physx
NVIDIA Image Scaling
NVIDIA Deep-Learning Super Sampling (DLSS)
NVIDIA RTX Ray Tracing
NVIDIA Ansel
NVIDIA NVENC Encode and Decode
NVIDIA Studio Drivers
GPU Switching: NVIDIA Optimus Advanced
MUX switch for faster graphics performance
Variable Refresh Support: Yes, supports G-Sync on external displays

Display
Size: 16″
Panel Type: IPS (In-Plane Switching)
Native Resolution: WUXGA (1920×1200)
Brightness: 300 nits (typical)
Contrast Ratio: 1000:1 (typical)
Colour Gamut: 72% NTSC, 100% sRGB, 75.35% Adobe RGB
Refresh Rate: 165Hz (Variable)
Variable Refresh Support: Yes, supports NVIDIA G-Sync

Storage
Installed: 1x 1TB M.2 2280 PCIe 4.0 x4 NVMe SSD
Supported: 1x M.2 2280 PCIe 4.0 NVMe SSD Slot (Occupied)

Connectivity
Ports: 1x Thunderbolt 4 USB Type-C Port with DisplayPort
1x USB 10Gbps Type-C Port with DisplayPort 1.4 & 100W Power Delivery 3.0
3x USB 5Gbps Type-A Ports
1x HDMI 2.1 (FRL) Port (Up to 8K @ 60Hz; UHD 4K @ 120Hz)
1x 3.5mm Combination Audio Jack
1x Gigabit Ethernet RJ-45 LAN Port

Audio
Speakers: 2x 2W Stereo speakers, supports HiRes Audio, Dolby Atmos support
Microphones: Array digital noise canceling microphones

Networking
Ethernet: Gigabit Ethernet RJ-45 LAN Port
Wi-Fi: WiFi 6E 2×2 MIMO Tri-Band Adapter
Bluetooth: Bluetooth 5.3
LTE: N/A

Integrated Input Devices
Keyboard: ASUS TUF Gaming 1-Zone RGB LED Backlit Chiclet Keyboard
Pointing Device: ASUS Precision Touchpad
Fingerprint Reader: N/A

General
Webcam: 1080P Full HD Webcam with Windows Hello
Operating System: Windows 11 Home 64-Bit
Battery: 90Wh, 4-Cell LI-Ion Integrated with Fast Charging
Power: 280W AC Adapter, Input: 100~240C AC 50/60Hz
Dimensions: 354 x 269 x 27.3mm (W x D x H)
Weight: 2.2kg
Colour: Jaegar Grey
