TECHNICAL SPECIFICATIONS
Brand: Gigabyte
Series: Socket AM4
Model: GA-A520M-S2H (rev. 1.0)
CPU: AMD Socket AM4, Support for: 3rd Generation AMD Ryzen Processors/ 3rd Generation AMD Ryzen with Radeon Graphics Processors
Click here to see the CPU support list.
Chipset: AMD A520
Memory: 2x DDR4 DIMM Sockets Supporting Up to 64 GB (32 GB Single DIMM Capacity) of System Memory
3rd Gen AMD Ryzen Processors:
Support for DDR4 5000(O.C.) / 4866(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz Memory Modules
3rd Gen AMD Ryzen with Radeon Graphics Processors:
Support for DDR4 5000(O.C.) / 4866(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz Memory Modules
Dual Channel Memory Architecture
Support for ECC Un-Buffered DIMM 1Rx8/2Rx8 Memory Modules
Support for Non-ECC Un-Buffered DIMM 1Rx8/2Rx8/1Rx16 Memory Modules
Support for Extreme Memory Profile (XMP) Memory Modules
On-Board Graphics Integrated in the 3rd Generation AMD Ryzen with Radeon Graphics Processors:
1x D-Sub Port, Supporting a Maximum Resolution of 1920×1200@60 Hz
1x DVI-D Port, Supporting a Maximum Resolution of 1920×1200@60 Hz
* The DVI-D port does not support D-Sub connection by adapter.
1x HDMI Port, Supporting a Maximum Resolution of 4096×2160@60 Hz
* Support for HDMI 2.1 version, HDCP 2.3, and HDR.
Support for Up to 3 Displays at the Same Time
Maximum Shared Memory of 16 GB
Audio: Realtek ALC887 Codec
High Definition Audio
2/4/5.1/7.1-Channel
* To configure 7.1-channel audio, you need to open the audio software and select Device advanced settings > Playback Device to change the default setting first. Please visit GIGABYTE’s website for details on configuring the audio software.
LAN Realtek GbE LAN Chip (1000 Mbit/100 Mbit)
Expansion Slots: CPU:
1x PCI Express x16 Slot, Supporting PCIe 3.0 and Running at x16
Chipset:
2x PCI Express x1 Slots, Supporting PCIe 3.0
Storage Interface: CPU:
1x M.2 Connector (Socket 3, M Key, Type 2242/2260/2280 SATA and PCIe 3.0 x4/x2 SSD Support)
Chipset:
4x SATA 6Gb/s Connectors
Support for RAID 0, RAID 1, and RAID 10
USB: CPU:
4x USB 3.2 Gen 1 Ports on the Back Panel
Chipset:
2x USB 3.2 Gen 1 Ports Available Through the Internal USB Header
6x USB 2.0/1.1 Ports (2 Ports on the Back Panel, 4 Ports Available Through the Internal USB Headers)
Internal I/O Connectors: 1x 24-pin ATX Main Power Connector
1x 8-pin ATX 12V Power Connector
1x CPU Fan Header
2x System Fan Headers
1x Addressable LED Strip Header
1x RGB LED Strip Header
1x M.2 Socket 3 Connector
4x SATA 6Gb/s Connectors
1x Front Panel Header
1x Front Panel Audio Header
1x USB 3.2 Gen 1 Header
2x USB 2.0/1.1 Headers
1x Trusted Platform Module (TPM) Header (2×6 pin, for the GC-TPM2.0_S Module Only)
1x Serial Port Header
1x Speaker Header
1x Chassis Intrusion Header
1x Clear CMOS Jumper
Back Panel Connectors: 1x PS/2 Keyboard/Mouse Port
1x D-Sub Port
1x DVI-D Port
1x HDMI Port
4x USB 3.2 Gen 1 Ports
2x USB 2.0/1.1 Ports
1x RJ-45 Port
1x Q-Flash Plus Button
3x Audio Jacks
I/O Controller iTE I/O Controller Chip
H/W Monitoring Voltage Detection
Temperature Detection
Fan Speed Detection
Overheating Warning
Fan Fail Warning
Fan Speed Control
* Whether the fan speed control function is supported will depend on the fan you install.
BIOS: 1x 128 Mbit Flash
Use of Licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Operating System Support: Windows 10 64-bit
Form Factor: Micro ATX Form Factor; 24.4cm x 20.5cm
