Samsung 870 EVO 1TB 2.5″ SATA 3.0 6 Gb/s Solid State Drive

Description

FEATURES
1TB Storage Capacity
2.5″ Form Factor
SATA 3.0 6 Gb/s Interface
Sequential Read Speed: Up to 560 MB/s
Sequential Write Speed: Up to 530 MB/s
4KB QD32 Random Read: Up to 98,000 IOPS
4KB QD32 Random Write: Up to 88,000 IOPS
AES 256-bit Encryption
Auto Garbage Collection Algorithm
Flash Memory: Samsung V-NAND 3bit MLC
Up to 1.5 Million Hours Reliability (MTBF)

TECHNICAL SPECIFICATIONS

Brand: Samsung
Series: 870 EVO
Model: MZ-77E1T0BW

General
Capacity: 1TB
Form Factor: 2.5 inch
Interface: SATA 6 Gb/s Interface, Compatible with SATA 3 Gb/s & SATA 1.5 Gb/s Interface
Storage Memory: Samsung V-NAND 3bit MLC
Controller: Samsung MKX Controller
Cache Memory: Samsung 1 GB Low Power DDR4 SDRAM
Dimensions: 100 x 69.85 x 6.8 mm
Weight: 45 g
Management Software: Magician Software for SSD Management, Data Migration Software for SSD Upgrade

Key Features
TRIM Support: Yes
S.M.A.R.T Support: Yes
Garbage Collection: Auto Garbage Collection Algorithm
Encryption Support: AES 256-bit Encryption (Class 0) TCG/Opal IEEE1667
Device Sleep Mode Support: Yes

Performance
Sequential Read: Up to 560 MB/s
Sequential Write: Up to 530 MB/s
Random Read (4KB, QD32): Up to 98,000 IOPS
Random Write (4KB, QD32): Up to 88,000 IOPS
Random Read (4KB, QD1): Up to 13,000 IOPS
Random Write (4KB, QD1): Up to 36,000 IOPS

Environment
Average Power Consumption: Average: 2.5 W
Maximum: 4.0 W (Burst mode)
Power consumption (Idle): Max. 30 mW
Reliability (MTBF): 1.5 Million Hours
Shock: 1,500 G & 0.5 ms (Half Sine)
Allowable Voltage: 5V ± 5%
Operating Temperature: 0 – 70 °C
