Vantec Link USB-C Multi-Function 11-in-1 Adapter with 100W Power Delivery

Description

FEATURES
Multi-Function
HDMI™ 2.0 Port (Max at 3840×2160 w/ 1 monitor@60Hz), with Audio
VGA (1920x1080p@60Hz) Video Port
Gigabit Ethernet RJ45 Port
SD 3.0 Memory Card Slot (SDXC, SDHC), Dual LUN
MicroSD Memory Card Slot (TF)
USB 3.1 Gen 2 (10Gbps), BC 1.2: 5V@1.5A, Type-C Port
USB 3.1 Gen 2 (10Gbps), BC 1.2: 5V@1.5A, Type-A Port
Two USB 2.0 Type-A Port
Headphone Jack (3.5 mm), In and Out, TRRS
USB C PD Port for 100W Max Power Delivery
Support Thunderbolt 3 and Thunderbolt 4
Support Laptop USB C Port with DP Alt Mode signal (DP v1.4)
Plug & Play; No Drivers Needed; USB hot-plugging
Durable Design with Heat Management using heatsink on chipset
Design for Mac OS X 10.x, or Windows 10/11, or ChromeBook with USB C port
Compact and Highly Integrated Design
Heat Management with Aluminum Casing and Durable design
Compliant to USB Type-C Cable & Connector Specs Rev 1.1
Compliant USB Power Delivery Specs Rev 2.0; Adaptive Voltage

TECHNICAL SPECIFICATIONS

USB Connector: USB Type-C (USB C reversible connector)

Device Connectors
1x HDMI™ 2.0 Port (4K60Hz), w/Audio
1x VGA (1920x1080p 60Hz) Video Port
1x Gigabit Ethernet RJ45 Port
1x SD Memory Card Slot (SDXC, SDHC), Dual-LUN
1x MicroSD Memory Card Slot (TF)
1x USB 3.1 Gen 2 (10Gbps), BC 1.2: 5V@1.5A, Type-C Port
1x USB 3.1 Gen 2 (10Gbps), BC 1.2: 5V@1.5A, Type-A Port
2x USB 2.0 Type-A Port
1x Headphone Jack (3.5 mm), In and Out, TRRS
1x USB C PD Port for 100W Max Power Delivery
Video Resolutions* Screen Display: Laptop – A, Monitor1 – B, Monitor2 – C
Using Windows OS
Laptop + HDMI HDMI: 3840×2160@60Hz, AB
Laptop + VGA VGA: 1920x1080p@60Hz, AB
Laptop + HDMI + VGA HDMI + VGA: Both at 1920x1080p@60Hz, ABC/ABB/AAA
Using Mac OS X
MacBook + HDMI HDMI: 3840×2160@60Hz, AB
MacBook + VGA VGA: 1920x1080p@60Hz, AB
MacBook + HDMI + VGA HDMI+VGA: Both at 1920x1080p@60Hz, ABB/AAA
* Note: ABB refer to monitor 1 and 2 in mirror mode; AAA refer to all 3 screen in mirror mode
Display capability depend on Laptop and OS capabilities, please check with Laptop manufacturer
Display Modes: Primary, Extended or Mirror (depend on OS capability and System capability)
Power Delivery: Dedicated USB C PD port for pass thru charging system with 100W Max
Power Supply: Bus-powered
Material: Aluminum, ABS Plastic
Dimensions: 137.2 x 60.4 x 20.5 mm
Weight: 157.7 g
Cable length: 165 mm
OS Support: Windows 10/11; Apple OS X 10.10, or greater; Latest ChromeBook; Linux

System Requirements
USB Type-C port MUST support DP Alt Mode for any Video Display
Optional Thunderbolt 3 or Thunderbolt 4 port
Optional device: HDMI Display device, USB device, SD Card, Network

Package Contents
Vantec Link USB C Multi-Function 11 in 1 Adapter With 100W Power Delivery Adapter
Quick Guide

Environmental
Operating Temperature 0 ℃ to +45℃
Operating Humidity 10% to 85 % RH (no condensation)
