Corsair 3500X RS-R ARGB Tempered Glass Black Steel E-ATX Mid-Tower Desktop Chassis

R2895

Get ready to build your next PC with the 3500X RS-R ARGB Mid-Tower Case from Corsair. Measuring in at 19.92 x 18.11 x 9.45″, this steel mid-tower case has two tempered glass panels on the front and side, allowing you to show off your latest equipment once you’ve finished your build. The 3500X RS-R is suitable for Mini-ITX, Micro-ATX, ATX, and E-ATX builds, giving you a wide variety of options for your custom setup.

In stock

Description

FEATURES
Panoramic Tempered Glass Front Panels
Corsair RapidRoute Cable Management
Corsair iCUE ARGB Lighting (Motherboard-Controlled)
Integrated GPU Support Arm with Airflow Guide
Mid-Tower ATX Form Factor
Supports E-ATX (277mm), ATX, Micro-ATX, Mini-ITX Motherboards
Supports Reverse Hidden Connector Motherboards
2x 2.5″ Drive Bays (Removable)
2x 3.5″ Drive Bay (Removable)
1x USB 20Gbps Type-C Port
2x USB 5Gbps Type-A Ports
1x 3.5mm Combination Audio Jack
Power Button, Reset Button
7x Horizontal PCI Slots
3x Pre-Installed Corsair RS-R ARGB PWM Reversed Fans (Side Intake)
Supports Up to 10x 120mm Fans
Supports Dual 360mm Radiators (Top, Front)
GPU Clearance: Up to 410mm
CPU Cooler Clearance: Up to 170mm
PSU Depth Clearance: Up to 180mm (Including Cables)
Compatible with Corsair Shift PSU Series
Colour: Black

TECHNICAL SPECIFICATIONS

Brand: Corsair
Series: 3500X Series
Model: 3500X RS-R Black (CC-9011322-WW)

Physical Details
Colour: Black
Materials: Aluminium
Steel
Tempered Glass
Side Panel: Panoramic Tempered Glass, mesh right side panel
Front I/O: 1x USB 20Gbps Type-C Port
2x USB 5Gbps Type-A Ports
1x 3.5mm Combination Audio Jack
Motherboard Support: E-ATX (305 x 277mm), ATX, Micro-ATX, Mini-ITX
Expansion Slots: 7x Horizontal PCI Slots
Drive Bays: 2x 3.5″ Drive Bays
2x 2.5″ Drive Bays
PSU Support: ATX
Dimensions: 460 x 240 x 506mm (D x W x H)
Weight: 9.02kg

Pre-Installed Fans
Front: N/A
Side: 3x Pre-Installed Corsair RS-R ARGB PWM Reversed Black Fans (Intake)
Top: N/A

Bottom
Rear: N/A

Fan Support
Front: N/A
Side: 3x 120mm or 2x 140mm Fans
Top: 3x 120mm or 2x 140mm Fans
Bottom: 3x 120mm or 1x 140mm Fan/s
Rear: 1x 120mm Fan

Radiator Support
Front: N/A
Side: 240 / 280 / 360mm Support
Top: 240 / 280 / 360mm Support
Bottom: 120mm Support
Rear: 120mm Support

Clearance
CPU Cooler Height Limitation: Up to 170mm
GPU Length Limitation: Up to 410mm
PSU Length Limitation: Up to 180mm (Including cables)
Cable Management: Yes, Corsair RapidRoute Cable Management with 38mm clearance

General
Dust Filters: Side, bottom, top dust filters
Chassis Lighting: Pre-installed Corsair RS-R fans support 3-pin 5V ARGB headers with 4-Pin PWM power.
Includes PWM and ARGB splitter cable for motherboard control, supports all major vendors

Additional information

Weight 22 kg
Dimensions 54,6 × 32,8 × 57,4 cm
Condition

Form Factor

ATX, Extended ATX, Micro ATX, Mini ITX

Side Panel

Windowed Side Panel

PSU Form Factor Support

ATX

Chassis Max GPU Length

410mm

Chassis Max CPU Cooler Height

170mm

Chassis Max Radiator Length

360mm

Frequently Asked Questions

Q: What motherboard sizes fit in this case?
A: This case supports ATX, Extended ATX, Micro ATX, Mini ITX motherboard form factors.

Q: What is the maximum graphics card length this case supports?
A: This case can accommodate graphics cards up to 410mm in length.

Q: What is the maximum CPU cooler height this case supports?
A: This case has clearance for air coolers up to 170mm tall.

Q: What size liquid cooling radiator can I install in this case?
A: This case supports radiators up to 360mm in length.

Q: What power supply form factor does this case support?
A: This case is designed to fit ATX power supplies.

Q: Does this case have a windowed side panel?
A: This case features a Windowed Side Panel, so you can show off the internal components.
